CURT TruTrack™ Weight Distribution System
The CURT TruTrack™ weight distribution hitch takes an innovative approach to combining weight distribution with sway control. It uses powerful spring bars to level the tow vehicle and trailer, while integrating two-position or four-position sway control to ensure a smooth ride.
TruTrack™ is the smarter choice because of its modern engineering and technology. It makes setup of the weight distribution system faster and easier, and it eliminates the need for you to purchase and install a separate sway control unit.
Mounting System
17520 - separated
Trailer-Mounted
17500
Hitch-Mounted
Level of Sway Control
17520 with arrows pointing to four points
4P
2P
TruTrack Hitch Comparison
TruTrack 4P Trailer-Mounted
The CURT TruTrack 4P trailer-mounted system provides an innovative coupling system that eliminates much of the hassle of hooking up (and unhooking) your trailer. Once the head and spring bar assembly are installed on the trailer tongue, there's no need to disassemble the components every time you want to uncouple.
TruTrack 2P Trailer-Mounted
The TruTrack 2P trailer-mounted is just like the 4P version, only instead of four pounts of integrated sway control, the 2P has just two points. It relies on strategic friction points to passively keep the trailer from swaying out of control. This provides cost savings for more budget-conscious users.
TruTrack 4P Traditional
The TruTrack 4P hitch ensures peaceful travel by incorporating sway control elements at four points that work together to keep the trailer aligned. The four touch points produce active sway control with the spring and cam system inside the head, along with the fixed spring bar hookups.
TruTrack 2P Traditional
The TruTrack 2P hitch delivers a smooth ride by incorporating sway control elements at two points that work together to keep the trailer aligned. The 2P’s dual points generate passive sway control with its fixed spring bar hookups alone. It does not include the spring and cam system.
TruTrack 4P Distinctives |
TruTrack 2P Distinctives |
Four distinct points of sway control | Two distinct points of sway control |
Spring and cam system + fixed hookup brackets | Fixed hookup brackets |
Trunnion-style, forged steel spring bars | Round, forged steel spring bars |
Up to 15,000 lbs. GTW | Up to 10,000 lbs. GTW |
