CURT Round Bar Weight Distribution Hitch #17002

UPC: 612314570027

Where To Buy

MSRP $342.80

  • Levels tow vehicle and trailer by redistributing a portion of the tongue weight
  • Equipped with round, forged steel spring bars for reliable strength
  • Heavy-duty, formed head can be adjusted for precise leveling
  • Features built-in sway control attachment tabs
  • 2" shank can be flipped to provide necessary drop or rise
  • 2 1/2" x 2 1/2" WD replacement shank also available
  • Snap-up brackets and lift handle allow for easy leveraging of spring bars
  • Protected by a highly durable carbide powder coat finish


  • Includes shank, spring bars, head, hookup brackets, pin & clip
  • Trailer ball not included
Primary Video
Instruction Sheet Download pdf
Side Application Type Description Blank
Warranty One Year Limited
Shipping Weight 87.000
Part Type Round Bar Weight Distribution Hitch
Mount Type Description Blank
Gross Trailer Weight(GTW) 10,000 LB
Tongue Weight(TW) 1,000 LB
Color Black
UPC 612314570027

Additional Information

The CURT weight distribution hitch is a specialized towing system that provides improved vehicle and trailer control by leveling the trailer and more evenly distributing its tongue weight across the trailer's and vehicle's axles. Weight distribution hitches are commonly used on travel trailers and campers but can also be applied to other large loads.

CURT WD hitches come with a 2" x 2" shank and are compatible with class 3, 4 and most 5 trailer hitches, including Xtra Duty and Commercial Duty (2 1/2" replacement WD shank may be required), as well as some RV trailer hitches. While a weight distribution hitch will increase the gross trailer weight capacity of most trailer hitches, the vehicle's weight carrying capacity must be taken into consideration before towing a heavier trailer (NOTE: Never exceed the lowest weight capacity of any towing component).

This round bar weight distribution hitch features a heavy-duty formed head and round spring bars constructed from forged steel. It offers a gross trailer weight capacity up to 10,000 lbs. and a tongue weight capacity of 1,000 lbs. It also includes hook-up brackets, spring bar safety chains and a pin and clip. To protect this hitch from scratching, chipping, rust and UV damage, it also comes with a durable black powder coat finish. A trailer ball must be purchased separately.


Submit Your Review

  • Cancel
Write a Review

Good but not great.

Bought this from a local vendor and within the first six months of towing my trailer I lost one of the Round Forged Steel Spring Bars as after some many uses the lock pin inset wore out and had to re-fasten the clip on. Not really a good design yet effective. After many uses the spring bars loosen up and just plain falls out. 3/5 stars as this really solved my slumping my back end of my truck I found a work around for loose spring bars.
